Startech
1PORT USB 2.0 EXTENDER OVER ETHERNET 330FT 100M
StarTech.com USB 2.0 Extender over Cat5e/Cat6 Cable (RJ45) - Locally or Remotely Powered Industrial Metal USB Extender Adapter Kit w/ ESD Protection - 330ft/100m - 480 Mbps, 65 mm, 88 mm, 30 mm, 170 g, 194 mm, 245 mm
MSRP
$702.11
Get a real, competitive price from a Dataworld account manager, usually the same day.
View your quote requestProduct identifiers
- SKU
- USB2001EXT2PNA
- UPC
- 0065030889728
- Category
- Input/Output Devices
Overview
StarTech.com USB 2.0 Extender over Cat5e/Cat6 Cable (RJ45) - Locally or Remotely Powered Industrial Metal USB Extender Adapter Kit w/ ESD Protection - 330ft/100m - 480 Mbps. Width: 65 mm, Depth: 88 mm, Height: 30 mm. Cables included: AC, USB. Power consumption (typical): 24 W, Input voltage: 100 - 240 V, Input current: 0.58 A. Master (outer) case width: 406 mm, Master (outer) case length: 558 mm, Master (outer) case height: 270 mm
Key features
- USB 2.0 EXTENDER: Extend a USB device up to 100m/330ft over CAT5e/CAT6 RJ45 ethernet network cable w/ data transfer rates up to 480Mbps; LEDs monitor power, activity status, link & host connectivity._x000D_
- CONNECT REMOTE USB DEVICES: The USB extender let's you remotely access USB devices like printers, cameras, plotters, keyboard/mouse, laser cutters, displays, or CCTV systems from a convenient location_x000D_
- INDUSTRIAL USB EXTENDER: Built w/ durable extruded aluminum construction for high wear & tear environments w/ mounting brackets incl; provides 8kV/16kV Contact/Air Electrostatic Discharge protection_x000D_
- POWERED USB EXTENDER KIT: The included power adapter enables the USB port to provide 5V, 500mA of power, and can be connected to either the local transmitter or the remote receiver_x000D_
- PLUG-AND-PLAY: The extender features driverless installation & is compatible w/ major operating systems incl. Windows, macOS, Linux; Backwards compatible with USB 1.0 and USB 1.1 devices_x000D_
- _x000D_
Specifications
Technical details
- Type
- Console transmitter & receiver
- Data transfer rate
- 480 Mbit/s
- Maximum transfer distance
- 100 m
- Product colour
- Black
- Housing material
- Plastic
- LED indicators
- Activity, Link, Power
- Cable types supported
- Cat5e, Cat6, Cat7
- Compliance certificates
- RoHS
- Certification
- CE, FCC, REACH
Ports & interfaces
- USB 2.0 Type-A ports quantity
- 1
- USB 2.0 Type-B ports quantity
- 1
- RJ-45 ports quantity
- 2
- DC-in jack
- Yes
Weight & dimensions
- Width
- 65 mm
- Depth
- 88 mm
- Height
- 30 mm
- Weight
- 170 g
- Package width
- 194 mm
- Package depth
- 245 mm
- Package height
- 78 mm
- Package weight
- 671 g
Operational conditions
- Operating temperature (T-T)
- 0 - 50 °C
- Storage temperature (T-T)
- -20 - 70 °C
- Operating relative humidity (H-H)
- 20 - 80%
Packaging content
- Cables included
- AC, USB
- Mounting kit
- Yes
- Manual
- Yes
- AC adapter included
- Yes
Power
- Power consumption (typical)
- 24 W
- Input voltage
- 100 - 240 V
- Input current
- 0.58 A
- Output voltage
- 24 V
- Output current
- 1 A
- Power plug type
- Type M
Logistics data
- Master (outer) case width
- 406 mm
- Master (outer) case length
- 558 mm
- Master (outer) case height
- 270 mm
- Products per master (outer) case
- 14 pc(s)
