APC by Schneider Electric
SMART-UPS 2200VA 120V LCD
APC Smart-UPS, 1.92 kVA, 1920 W, Sine, 75 V, 154 V, 50/60 Hz
MSRP
$2,425.00
Quantity
Get a real, competitive price from a Dataworld account manager, usually the same day.
View your quote requestProduct identifiers
- SKU
- SMT2200US
- UPC
- 0731304305620
- Category
- Power Protection / UPS
Overview
APC Smart-UPS. Output power capacity: 1.92 kVA, Output power: 1920 W, Waveform: Sine. AC outlet types: NEMA 5–15R, NEMA 5–20R, Power plug: NEMA 5-20P, AC outlets quantity: 10 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Typical backup time at full load: 7.5 min, Typical backup time at half load: 22.5 min. Form factor: Tower, Product colour: Black, Cable length: 1.83 m. Compliance certificates: RoHS
Specifications
Features
- Output power capacity
- 1.92 kVA
- Output power
- 1920 W
- Waveform
- Sine
- Input operation voltage (min)
- 75 V
- Input operation voltage (max)
- 154 V
- Input frequency
- 50/60 Hz
- Surge energy rating
- 530 J
- Efficiency
- 98%
- Emergency Power Off (EPO)
- Yes
- Output voltage Total Harmonic Distortion (THD)
- 5%
- Noise level
- 45 dB
- Audible alarm(s)
- Yes
- Audible alarm modes
- Battery replacement
Ports & interfaces
- AC outlet types
- NEMA 5–15R, NEMA 5–20R
- Power plug
- NEMA 5-20P
- AC outlets quantity
- 10 AC outlet(s)
- USB 2.0 ports quantity
- 1
Battery
- Battery technology
- Sealed Lead Acid (VRLA)
- Typical backup time at full load
- 7.5 min
- Typical backup time at half load
- 22.5 min
- Battery recharge time
- 3 h
- Replacement battery cartridge
- RBC55
Design
- Form factor
- Tower
- Cable length
- 1.83 m
- Product colour
- Black
- Display type
- LCD
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Storage temperature (T-T)
- -15 - 45 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Storage relative humidity (H-H)
- 0 - 95%
- Operating altitude
- 0 - 3000 m
- Non-operating altitude
- 0 - 15000 m
Certificates
- Compliance certificates
- RoHS
Sustainability
- Sustainability certificates
- ENERGY STAR
Weight & dimensions
- Width
- 196 mm
- Depth
- 544 mm
- Height
- 432 mm
- Weight
- 50.9 kg
Packaging data
- Package weight
- 60.9 kg
Other features
- Nominal output voltage
- 120 V
- Nominal input voltage
- 120 V
- Output connection type
- 8 x NEMA 5-15R & 2 x NEMA 5-20R
- Package dimensions (WxDxH)
- 381 x 762 x 559 mm
